DRUM FILTRATION SYSTEM + COMBI

✅ SeaSide C-22 Combi RDF

Unit comes with 1 bag of k1 media, air pump, external cleaning up ( required installation )

Specifications C-22

MAX FLOW 5800GPH

Pond suggested 15000GAL

Standard flow is 22 m3 / h

Gravity / Airlift / Pump fed

Installation height 17 cm

Material:

PP 15 mm housing / PP 20 mm drum

Stainless steel 316/304 / Silicone seal

Specifications:

2 x 110 mm inputs

2 x 110 mm outputs ( 2 extra 110 mm outputs for pump fed )

110 mm waste water drain

Diameter drum 40 x 40 cm

Screen panel 75 micron stainless steel 316

Removable waste water container

Spray bar with removable mounting, high pressure PVC 40 bar Cover

Media 200L

Air Disc 35cm

Air Disc Connection 20/25mm

Control box on filter

Turn / flush manual operation

Rinse level adjustable

Turn / rinse time adjustable

All components assembled in modules and therefore quickly interchangeable

✅ SeaSide CL-35 Combi RDF



Unit comes with bag of k1 media, air pump, external cleaning up ( required installation )

Specifications CL-35

Max Flow 9250GPH

Pond suggested 22000GAL

Standard flow is 35 m3 / h

Gravity / Airlift / Pump fed

Installation height 14 cm

Material:

PP 15 mm housing / PP 20 mm drum

Stainless steel 316/304 / Silicone seal

Specifications:

3 x 110 mm inputs

3 x 110 mm outputs ( 2 extra 110 mm outputs for pump fed )

110 mm waste water drain

Diameter drum 40 x 40 cm

Screen panel 75 micron stainless steel 316

Removable waste water container

Spray bar with removable mounting, high pressure PVC 40 bar Cover

Media 150L

Air Disc 35cm

Air Disc Connection 20/25mm

Control box on filter

Turn / flush manual operation

Rinse level adjustable

Turn / rinse time adjustable

All components assembled in modules and therefore quickly interchangeable

✅ SeaSide CL-65 Combi RDF



Unit comes with 1 bag of k1 media, air pump, external cleaning up ( required installation )

Specifications CL-65

Max Flow 17000GPH

Pond Suggested 40000GAL

Standard flow is 65 m3 / h

Gravity / Airlift / Pump fed

Installation height 14 cm

Material:

PP 15 mm housing / PP 20 mm drum

Stainless steel 316/304 / Silicone seal

Specifications:

3 x 110 mm inputs

3 x 110 mm outputs ( 2 extra 110 mm outputs for pump fed )

110 mm waste water drain

Diameter drum 60 x 50 cm

Screen panel 75 micron stainless steel 316

Removable waste water container

Spray bar with removable mounting, high pressure PVC 40 bar Cover

Media 350L

Air Disc 35cm

Air Disc Connection 20/25mm

Control box on filter

Turn / flush manual operation

Rinse level adjustable

Turn / rinse time adjustable

All components assembled in modules and therefore quickly interchangeable

✅ SeaSide Eco 20 RDF w/ Bakki Shower

 external cleaning up ( required installation ) Specifications Eco-20

MAX Flow 5800GPH

Pond Size Suggested 14000GAL

Standard flow is 25 m3 / h

Gravity / Airlift / Pump fed

Installation height 17 cm

Material:

PP 10 mm housing / PP 15 mm drum

Stainless steel 316/304 / Silicone seal

Specifications:

2 x 110 mm inputs

2 x 110 mm outputs ( 2 extra 110 mm outputs for pump fed )

110 mm waste water drain

Diameter drum 38 x 40 cm

Screen panel 120 micron stainless steel 316

Removable waste water container

Spray bar with removable mounting, high pressure PVC 40 bar Cover

Control box on filter

Turn / flush manual operation

Rinse level adjustable

Turn / rinse time adjustable

All components assembled in modules and therefore quickly interchangeable

✅ SeaSide Bio Moving Bed Chamber BK60

Sea Side Aquatics Bio Chamber BK60



Approximately 905 mm x 570mm (36 x 22.5″)



Max Flow: 35m3



Max Helix: 100 Liters



The Bio Chamber comes complete with one 32cm Air Disc



Visit here for more pictures and details
